| Screwdriver Tip Configurations |
 |
|
| |
 |
Slotted: Standard or flat for driving
single slotted screws. Tip width range from 1/6"
to 1/2". |
 |
Phillips®: Designed specifically for
use with Phillips® head screw, which has
two recessed slots at right angles to each other. Sizes
range from 0 point (small) to 4 point (large). |
 |
Pozidriv®: Similar to the Phillips®
style, the screw can be identified by additional lines
on the face. Sizes range from 1 point (small) to 4 point
(large). |
 |
Square head: Square tip, used in mobile homes, recreational
vehicles and industrial applications. Sizes range from
1 point (small) to 3 point (large). |
 |
Torx®: Star shaped, used in the automotive
industry. Sizes range from T-10 (small) to T-30 (large).
|
|
| |
|
| Screwdriver Safety Tips |
|
|
 |
Never use a screwdriver as a cold
chisel, or for prying, punching, chiseling, scoring or scraping.
|
 |
|
Make sure the tip fits the slot of
the screw; not too loose or tight.
|
|
Never expose a screwdriver to excessive
heat or cold.
|
|
Always discard a screwdriver with
a worn or broken handle.
|
|
Never use a screwdriver on a workpiece
held in your hand. A slip could cause serious injury.
|
|
Never depend on a screwdrivers' handle
or covered blade to insulate you from electricity.
|
|
Vinyl covered blades are intended only as a
protective measure against shorting out components. |
| |
|
